Custom Molded EPE Physical Properties
Physical Properties
|
Test Method
|
Units
|
Typical Values
|
| Density |
ASTM-D3575 |
pcf (g/l) |
1.30 (20) |
1.5 (24) |
1.90 (30) |
Compressive Strength
@25% Strain
@50% Strain
@75% Strain |
ASTM-D3575
|
psi
psi
psi |
9.5
17.5
44.0 |
10.5
19.0
49.0 |
12.5
22.0
56.0 |
| Compressive Set |
ASTM-D3575 |
25% (50%) |
3.0 (14.0) |
4.2 (12.5) |
4.8 (12.0) |
| Tensile Strength |
ASTM-D3575 |
psi |
39.2 |
44.7 |
51.4 |
| Tensile Elongation |
ASTM-D3575 |
% |
32.0 |
30.0 |
28.5 |
| Tear Strength |
ASTM-D3575 |
lbs/in |
14.0 |
15.5 |
17.0 |
| Buoyancy |
ASTM-D3575 |
pcf |
60.6 |
60.2 |
59.5 |
| Compressive Creep |
ASTM-D3575
1000 hrs @ 1 psi |
% |
2.8 |
3.0 |
3.3 |
| Thermal Conductivity |
ASTM-C177 |
(K) BTU-in/ft²-hr-ºF |
0.26 |
0.25 |
0.24 |
| Thermal Resistance |
ASTM-C177 |
(R) |
3.9 |
4.0 |
4.2 |
| Flammability |
FMVSS-302 |
<4.0 in/min. |
Pass |
Pass |
Pass |
Chemical Resistance
(Auto fuels, fluids, solvents) |
Various |
1 hr exposure |
Pass |
Pass |
Pass |
Note: Typical values Shown
pcf = pounds/cubic foot, g/l = grams per liter
The information contained herein is based upon the results of limited laboratory tests on test samples of material molded from expanded polyolefin resin manufactured by JSP, www.jsp.com. There can be no assurance that the similar results will be achieved in simulated tests or actural use of commercial product molded by customers of ACH Foam Technologies. Product performance may vary substantially depending upon the particular application or processing involved. The listed properties are illustrative only and not the product specifications. All suggestions and recommendations are made without warranty since the conditions of use are beyond ACH Foam Technologies' control. Processing and applications of foam products can influence molded part performance in many ways. Consequently, processors and/or users are advised that there may be a need to conduct independent tests and experiments in order for them to determine the extend to which they may choose to rely upon such information in their business operations. ACH Foam Technologies disclaims any liability in connection with the use of the information and doe snot warrant against infringement by reasons of the use of its products.
