SIPs...helping you save.
Energy Efficiency
A 4 1 / 2 " thick R-Control Structural Insulated Panel wall was tested against 2x4 and 2x6 traditionally framed walls. The R-Control Structural Insulated Panel significantly outperformed 2x4 stud walls and also outperformed thicker 2x6 stud walls. Results are conclusive, 4 1 / 2 " R-Control Structural Insulated Panels have better whole wall R-value than 2x6 batt insulated construction.

SIPS ProductThe test program was sponsored by the Structural Insulated Panel Association (SIPA). Testing demonstrated that Structural Insulated Panel connections did not create cold spots. This contrasted to stick built walls which had cold spots over each lumber stud in the testing. Dramatically reducing cold spots provides a more comfortable interior environment, an advantage in building with R-Control Structural Insulated Panels.

SIP
Thickness
R-Value
at 75 F
R-Value
at 40 F
4 1/2 " 14.9 16.0
6 1/2" 22.6 24.3
8 1/4" 29.3 31.6
10 1/4 " 37.0 39.9
12 1/4 " 44.7 48.3




Download a PDF file of our SIPs brochure.
Downloadable roofing Brochure

Download a PDF file of our Performance Update.
Downloadable SIPs Brochure
